| 材质 | 尼龙 |
|---|---|
| 转向 | 万向脚轮 |
| 规格 | 30-60mm |
| 加工定制 | 是 |
| 用途 | 家具脚轮 |
| 直径 | 30-60mm（mm） |
| 自重 | 40（kg） |
| 适用范围 | 办公设备 轻型橱柜 小型置物架 |
| 品牌 | 锐迪 |
| 型号 | 30-60mm |
无刹万向轮 配件选用螺杆，S轴，方盘，卡环插杆，插杆和U形夹
S轴/插杆配用塑料套
有刹脚轮带配件
| 有刹脚轮 | 螺杆 | S轴 | 方盘 | 卡环插杆 | 插杆 | U型夹 | |||||
| 轮径 | M6*15 | M8*15 | M10*15 | ¢8*38 | 35x35x1.5 | 35x35x2.0 | 38*38*2.0 | ¢8*18 | ¢6*12 | ¢6*20 | 33x16 |
| 30 | CH30BM1615 | CH30BS838 | CH30BP3501 | CH30BK818 | CH30BN612 | CH30BN620 | CH30BU3316 | ||||
| 40 | CH40BM815 | CH40BM1015 | CH40BS838 | CH40BP3501 | CH40BP3502 | CH40BK818 | CH40BU3316 | ||||
| 50 | CH50BM815 | CH50BM1015 | CH50BS838 | CH50BP3502 | CH50BK818 | CH50BU3316 | |||||
| 60 | CH60BM1015 | CH60BS838 | CH60BP3802 | CH60BK818 | CH60BU3316 | ||||||
S轴和插杆必选配件
| 有刹脚轮 | 插杆塑料套 | S轴塑料套 | 插杆塑料套 |
| 轮径 | ¢13*15 | ¢13*35 | ¢11*17 |
| 30 | SPB1315 | SPS1335 | SPK1117 |
| 40 | SPB1315 | SPS1335 | SPK1117 |
| 50 | SPB1315 | SPS1335 | SPK1117 |
| 60 | SPB1315 | SPS1335 | SPK1117 |
